DC Micro Motor for Computer Peripherals


Computer equipment has become remarkably popular in the last two decades. EVERCOM has responded to the rapid development of this market with a powerful production system.
We want to produce high quality products in a more cost effective way and in a timelier manner. Our streamlined production system has been established to achieve customer satisfaction. We have been able to cope with our customer’s changing needs by thorough cost reduction, and the use of streamlined mass production. EVERCOM has been developing its unique highly advanced mass production technology and streamlined production system in order to improve productivity and quality. We believe that
“Quality is made in the manufacturing process” so we have been applying a maximum effort to the education of human resources, improvement of process control, enhancement of production facilities and making a continuous effort to improve our products’ quality.
At EVECOM we build continuous improvement into our production systems and pursue ”high quality, low cost and quick delivery”.



                               DC Micro Motor for Computer Peripherals
DC MOTOR FOR VCR Polygonal Mirror Scanner

EM100 series
EM200 series
ELM series

Model
Rated Voltage
Rated Speed
Mirror Size
Starting Time
(sec)
Rated Current
(A)
Jitter
EM100 series
DC24V
43,000/min Max
15,000/min Min
at Φ34.64mm mirror
Typical size Φ34.64mm
Maximum size Φ43mm
5
at Φ40mm mirror
30,000/min
0.7 Max.
at Φ40mm mirror
30,000/min
0.01% Max.
(Low freq. Jitter)
EM200 series
DC24V
50,000/min Max
15,000/min Min
at Φ36mm mirror
Typical size Φ50mm
Maximum size Φ70mm
12
at Φ50mm mirror
40,000/min
1.9 Max.
at Φ50mm mirror
40,000/min
0.01% Max.
(Low freq. Jitter
ELM
series
DC24V
38,000/min Max
15,000/min Min
at Φ34.64mm mirror
Typical size
Φ34.64mm
Maximum size Φ40mm
4
at Φ36.64mm mirror
30,000/min
0.3 Max.
at Φ36.64mm mirror
30,000/min
0.01% Max.
(Low freq. Jitter


DC MOTOR FOR VCR

For Camcorders (Digital)
Capstan Motors
EB4HJ
Φ25
Axial-gap type
Three phase brushless

With frequency generator
Compact and light weight
Drum Motors
EI4FD

Φ25
Axial-gap type
Three phase brushless
With frequency generator Compact and light weight
For Camcorders (8mm)
Capstan Motors
E4HJ

Φ25
Axial-gap type
Three phase brushless
With frequency generator
Compact and light weight
Drum Motors
EI3KD

Φ25
Axial-gap type
Three phase brushless
With frequency generator
Compact and light weight
