| FANTECH
is a leader in the electronic thermal management field.For more than twenty years years FANTECH has developed a broad range of products designed to extend the life of electronic components primarily used for the information technology industry. Fan motors work to quickly disperse heat and Now, we develop and manufacture on two |
|
  |
Copyright © 2006 TELSTAR International Technology Co., Ltd/EVERCOM Group. All Rights Reserved.
Please contact telst@ms67.hinet.net
for more detailed technical spec. data/drawing
Please contact telst@ms67.hinet.net for more detailed technical spec. data/drawing
Please contact telst@ms67.hinet.net for more detailed technical spec. data/drawing
 |
FP-HS-015G For intel Pentium III Up to 1.3GHz For AMD Athlon Up to 1.2GHz Fan Size: �T 60x60x15mm Bearing System: Sleeve/Ball Rated Voltage: 12VDC Speed: 4500 rpm Heat sink size: �T60x60x40mm |
 |
FP-HS-260G For intel Pentium IV Up to 2.2~2.4GHz For Intel Celeron Up to 1.6~1.7GHz Fan Size: �T 70x70x15mm Bearing System: Sleeve/Ball Rated Voltage: 12VDC Speed: 4200 rpm Heat sink size: 90x70x37mm |
 |
FP-HS-512G For intel Pentium IV Up to 2.0~2.2GHz Fan Size: �T 80x80x25mm Bearing System: Sleeve/Ball Rated Voltage: 12VDC Speed: 3000 rpm Heat sink size: �T80x80x39mm |
 |
FP-HS-621G For intel Pentium IV Up to 2.0~2.2GHz Fan Size: �T 70x70x15mm Bearing System: Sleeve/Ball Rated Voltage: 12VDC Speed: 4200 rpm Heat sink size: �T83x69x37mm |
Please contact telst@ms67.hinet.net for more detailed technical spec. data/drawing
 |
 |
 |
 |
 |
 |
- OPERATING TEMPERATURE: -10°C ~ 70°C (ORDINARY HUMIDITY)
- STORAGE TEMPERATURE: -40°C ~ 70°C (ORDINARY HUMIDITY)
- INSULATION RESISTANCE: 10MΩ AT 500VDC
- DIELECTRIC STRENGTH: BETWEEN LEAD OR TERMINAL AND HOUSING 700VAC FOR 3 SEC OR 500VDC FOR 1MIN.
- VIBRATION TEST: JIS C0040 1.5mm FREQUENCY 10~55Hz 1 HOUR IN 3 DIRECTION X,Y,Z, EACH
- SHOCK TEST: JIS C0041 GRAVITATIOAL ACCELERATION 100G TIME 6 SEC IN 3 DIRECTIONS X.Y.Z. EACH.
- LIFE: AMBIENT TEMPERATURE 25°C AND HUMIDITY 65%
•SLEEVE BEARING: 30,000 HOURS
•BALL BEARING : 50,000 HOURS - LOCKED ROTOR PROTECTION: 72 HOURS AT RATED VOLTAGE
- POLARITY PROTECTION: REVERSE CONNECTION AT THE RATED VOLTAGE WILL NOT CAUSE ANY DAMAGE.
- INSULATION CLASS: E CLASS (UL: CLASS A)
•ADDITIONAL PERFORMANCE REQUIREMENTS CAN BE DETERMINED BETWEEN MANUFACTURER AND CUSTOMER, BASED ON CUSTOMER’S REQUEST.
•DESIGN IMPROVEMENTS WILL BE INCORPORATED WITHOUT PRIOR NOTICE.
•STORAGE TERMS SHOULD NOT EXCEED 6 MONTHS AND FANS SHOULD NOT BE STORED IN HIGH
HUMIDITY AREA
- OPERATING TEMPERATURE: -20°C ~ 85°C (ORDINARY HUMIDITY)
- STORAGE TEMPERATURE: -30°C ~ 140°C (ORDINARY HUMIDITY)
- INSULATION RESISTANCE: 100MΩ AT 500VDC
- DIELECTRIC STRENGTH: BETWEEN TERMINAL AND HOUSING 1500VAC FOR 1 SEC.
- VIBRATION TEST: VIBRATION OF ACCELERATION 2.5G FREQUENCY 10~55Hz TIME 1 MIN 3 DIRECTION X,Y,Z,EACH
- SHOCK TEST: GRAVITATIONAL ACCELERATION 60G IN 3 DIRECTION X,Y,X,EACH
- LIFE: AMBIENT TEMPERATURE 25°C AND HUMIDITY 65%
•SLEEVE BEARING: 30,000 HOURS
•BALL BEARING : 50,000 HOURS - LOCKED ROTOR PROTECTION: 72 HOURS AT RATED VOLTAGE
- POLARITY PROTECTION: REVERSE CONNECTION AT THE RATED VOLTAGE WILL NOT CAUSE ANY DAMAGE
- INSULATION CLASS: B CLASS (UL: CLASS A)
•ADDITIONAL PERFORMANCE REQUIREMENTS CAN BE DETERMINED BETWEEN MANUFACTURER AND CUSTOMER, BASED ON CUSTOMER’S REQUEST.
•DESIGN IMPROVEMENTS WILL BE INCORPORATED WITHOUT PRIOR NOTICE.
•STORAGE TERMS SHOULD NOT EXCEED 6 MONTHS AND FANS SHOULD NOT BE STORED IN HIGH HUMIDITY AREA
